Knuckle Boom Truck Mounted Cranes

Knuckle Boom Truck Mounted Cranes

Knuckle boom truck mounted cranes are perfect for lifting and moving things around using different attachments. Even though they are compact in design, they still do the heavy lifting. They are made from quality materials, which means you will get years of service out of them.

BOB-LIFT has some of the best knuckle boom truck mounted cranes in the market. We have been in the business for a while now and will ensure you get the best in the market. Our cranes are made from the best materials and we offer tips on how you can make them work for you. Talk to us today and let us help you revolutionize your growth.


  • 16 Ton Knuckle Boom Truck Mounted Crane
    16 Ton Knuckle Boom Truck Mounted Crane
    Some characteristics that can help you understand how the 16 Ton Knuckle Boom Truck Mounted Crane works are its 16-ton maximum lifting capacity, 40 Ton.m maximum lifting moment. The set-up space should be at least 1500mm. It weighs 5000 kg, and has a 360-degree rotation angle.
    Inquire
  • 3.2 Ton Knuckle Boom Truck Mounted Crane
    3.2 Ton Knuckle Boom Truck Mounted Crane
    The 3.2 Ton Knuckle Boom Truck Mounted Crane allows for a 3200 kg maximum lifting capacity, in varying environments and a 6.8 Ton.m maximum lifting moment. Other characteristics are a 25 L/Min hydraulic system flow and a 14KW recommended power. The crane's oil tank can hold up to 60 L of oil and it has a 400-degree rotation angle.
    Inquire
  • 25 Ton Knuckle Boom Truck Mounted Crane
    25 Ton Knuckle Boom Truck Mounted Crane
    Some specs that might help you understand how the crane works are its 25000 kg maximum lifting capacity, 62.5-ton maximum lifting moment and 7850 kgs weight. It comfortably fits on a 1500mm installation space, and allows a 360-degree rotation angle.

    Inquire
  • 4 Ton Knuckle Boom Truck Mounted Crane
    4 Ton Knuckle Boom Truck Mounted Crane
    The 4-ton maximum lifting capacity and 8.4-ton.m maximum lifting moment guarantee operation efficiency of our 4-ton Knuckle Boom Truck Mounted Crane. Some other beneficial features are its 25L/min hydraulic system flow and the 26Mpa hydraulic system pressure. You will require an 859mm set up space which is suitable for the crane’s 400-degree rotation angle and 1250 kgs weight.
    Inquire
  • video 10 Ton Knuckle Boom Truck Mounted Crane
    10 Ton Knuckle Boom Truck Mounted Crane
    The 10 ton knuckle boom truck mounted crane has a 10 ton maximum lifting capacity and a 20 ton.m maximum lifting moment. It has a 25KW recommended power and a 40 L/min hydraulic system flow. The crane requires a 1200mm installation space and has a 380-degree rotation angle.

    Inquire
  • video 12 Ton Knuckle Boom Truck Mounted Crane
    12 Ton Knuckle Boom Truck Mounted Crane
    This crane has a 12 ton maximum lifting capacity and a 27 ton.m maximum lifting moment. It has a 30 KW recommended power, a 55l/min hydraulic system flow, and a 160 L oil tank capacity. The crane requires a 1400mm installation space and has a 380-degree rotation angle.

    Inquire
  • video 2 Ton Knuckle Boom Truck Mounted Crane
    2 Ton Knuckle Boom Truck Mounted Crane
    The 2 Ton Knuckle Boom Truck Mounted Crane has a 2000 kg maximum lifting capacity, a 4.2 ton maximum lifting moment, and a 20 L/min hydraulic system flow. It has a 9KW recommended power, a 25L oil tank capacity, and a 370-degree rotation angle.

    Inquire
  • video 5 Ton Knuckle Boom Truck Mounted Crane
    5 Ton Knuckle Boom Truck Mounted Crane
    The 5-ton Knuckle Boom Truck Mounted Crane has a 5-ton maximum lifting capacity and a 10.5-ton maximum lifting moment. It has a 35L/min hydraulic system flow, a 28 Mpa hydraulic system pressure, and a 1050mm installation space. The crane weighs 1850kgs and has a 400-degree rotation angle.

    Inquire
Xuzhou BOB-LIFT Construction Machinery Co., Ltd. is a high-tech enterprise specializing in the design, development, manufacture and sales of truck-mounted cranes. With a factory area of over 37,000 square meters, the company's main products include SQ08-SQ55 series of folding and telescopic boom truck-mounted cranes and related variants such as truck mounted crane, marine crane, pickup crane.
