Telescopic Boom Marine Cranes

SQ3.2SA3T3.2 Ton Telescopic Boom Marine Crane SQ3.2SA3T

Previous model No longer in regular production. It can still be built to order.

Current model View SQ3.2SA4T Compare with the current range

SQ: Truck mounted crane
3.2: 3.2 t capacity class
S: Telescopic boom
A3: 1 main boom + 2 hydraulic booms
T: Marine version

Max Lifting Capacity: 3200kg
Max Lifting Moment: 6.8t·m
Recommended Power: 14kW
Hydraulic System Flow: 25L/min

Download PDF8.3 MB

Or message us +86 158 5249 9415 info@boblift.com

12-month warranty
Order from 1 unit
Shipping & warranty

Confirm your configuration and current availability with our team.

3.2 Ton Telescopic Boom Marine Crane SQ3.2SA3T

Engineering data

SQ3.2SA3T Specifications

Lifting

Max Lifting Capacity: 3200kg
Max Lifting Moment: 6.8t·m
Rotation Angle: 360°

Hydraulics and power

Recommended Power: 14kW
Hydraulic System Flow: 25L/min
Hydraulic System Pressure: 20MPa
Oil Tank Capacity: 60 L

Machine

Self Weight: 1050kg

Figures from the BOB-LIFT brochure for this range. Confirm the final specification with our team before ordering.

Compare all Telescopic Boom Marine Cranes

Dimensions and load chart

Select the drawing to view it full size.

Product details · SQ3.2SA3T

3.2 Ton Telescopic Boom Marine Crane SQ3.2SA3T

The SQ3.2SA3T is a 3.2 t telescopic boom marine crane with a maximum lifting moment of 6.8 t·m. It runs on a recommended 14 kW power supply with 25 L/min of hydraulic flow at 20 MPa, weighs 1050 kg and offers 360° slewing.

Capacity class

3.2 t

Max lifting moment 6.8 t·m
Telescopic boom sections

3

1 main boom + 2 hydraulic booms
Hydraulic flow

25 L/min

20 MPa · 14 kW recommended

Choosing the right model

Need more than 3.2 t? The next class up is the SQ4SA3T at 4 t. For lighter loads, the SQ2SA3T at 2 t is the class below.

Before ordering, check that the vessel's hydraulic supply can deliver 25 L/min at 20 MPa. We recommend 14 kW of hydraulic power.

Telescopic Boom Marine Crane

Product technical advantages

High-strength steel structure

Compact, light and strong steel structure.
Custom installation

Pedestal mounting tailored to your deck.
Optional attachments

Winch, drill pipe, basket or grapple.
Operation modes

Manual levers, overhead seat or wireless remote.

Dedicated torque limiter Load moment limiter, safety certified.
Marine anti-rust treatment Multi-layer anti-rust process for sea duty.

Manufacturing & delivery

From our workshop to your port

01

Boom sections

Telescopic boom sections are finished and fitted before assembly.
02

Assembly

Columns, winches and control valves are assembled in our Xuzhou workshop.
03

Marine test stand

Mounted on a deck-style stand, the crane runs every boom and slewing motion before release.
04

Packing

Wrapped in film and strapped to protect paint and hydraulics in transit.
05

Container loading

Loaded into containers at the factory and shipped to your port.

Shipping & warranty

Shipping, warranty and documents

How the SQ3.2SA3T reaches you, and what happens after it arrives.

Shipping

Lead time and container loading are confirmed with your quotation.

Warranty and parts

12 months

Send the model, serial number and a photo or video of the issue; our team guides the repair and ships the parts.

Order from 1 unit

Documents

Marine Cranes Brochure

PDF · 12 pages · 8.3 MB

Download PDF
Dimensions and load chart
SQ3.2SA3T Specifications

FAQ

Questions about the SQ3.2SA3T

About the SQ3.2SA3T

01 What hydraulic supply does the SQ3.2SA3T need?

25 L/min at 20 MPa. We recommend 14 kW of hydraulic power. Send us the vessel's hydraulic data and we confirm the match when we quote.

02 What warranty and minimum order apply to the SQ3.2SA3T?

The SQ3.2SA3T carries a 12-month warranty, and you can order from 1 unit.
