SQ5SA2F5.15 Ton Tow Truck Crane

SQ: Truck mounted crane
5: 5 t capacity class
S: Telescopic boom
A2: 1 main boom + 1 hydraulic boom
F: Flip-over outriggers

Max Lifting Capacity: 5150kg
Max Lifting Moment: 14.5t·m
Recommended Power: 22kW
Hydraulic System Flow: 35L/min

Download PDF14.4 MB

Or message us +86 158 5249 9415 info@boblift.com

12-month warranty
Order from 1 unit
Shipping & warranty

Confirm your configuration and current availability with our team.

5.15 Ton Tow Truck Crane

Engineering data

SQ5SA2F Specifications

Lifting

Max Lifting Capacity: 5150kg
Max Lifting Moment: 14.5t·m
Rotation Angle: 400°

Hydraulics and power

Recommended Power: 22kW
Hydraulic System Flow: 35L/min
Hydraulic System Pressure: 28MPa

Machine

Installation Space: 850mm

Reach and outriggers

Max. radius: 6.2m
Max. height: ≈ 8.5 m
Max. boom angle: 70°
Outrigger span: 2260–5120 mm

Figures from the BOB-LIFT brochure for this range. Confirm the final specification with our team before ordering.

Compare all Other Cranes

Dimensions and load chart

Select the drawing to view it full size.

How much it lifts at each reach The further the hook is from the crane, the less it can lift: 5,150 kg at 2.35 m, 1,850 kg at 6.2 m.

Lifts (kg)	5,150	2,650	1,850
Reach (m)	2.35	4.25	6.2

Reach is measured from the slewing centre to the hook. Figures from the drawing above.

Product details · SQ5SA2F

5.15 Ton Tow Truck Crane

The BOB-LIFT SQ5SA2F tow truck crane has a maximum lifting capacity of 5150 kg and a maximum lifting moment of 14.5 t·m.
